| Local Area Network Architecture | 10Base-T/100Base-TX/1000Base-TX |
| Data Link Protocol Supports | Gigabit Ethernet/Fast Ethernet/Ethernet |
| Total Number of Ports | 24 |
| Switching Protocol | Ethernet |
| Networking Compliant Standards | IEEE 802.1p(QoS) <br/>IEEE 802.1Q(VLAN) <br/>IEEE 802.3 <br/>IEEE 802.3ab <br/>IEEE 802.3u <br/>IEEE 802.3x |
| Networking Features | Auto-Negotiation <br/>MDI/MDI-X switch |
| Device Location | External |
| Certifications | FCC, CE, RoHS |
| Ethernet 10Base-T/100Base-TX/1000Base-TX Port Quantity | 16 |
| Ethernet 10Base-T/100Base-TX/1000Base-TX Port Connector Type | RJ-45 |
| Requires Operating System | Apple Mac OS <br/>Linux <br/>Microsoft Windows 98SE <br/>Microsoft Windows NT <br/>Microsoft Windows XP <br/>Novell Netware <br/>Unix <br/>Microsoft Windows Vista <br/>Microsoft Windows 7 <br/>Microsoft Windows 8 |
| Power Device Location | Internal |
| Maximum Input Frequency | 60 Hz |
| Maximum Input Voltage | 240 V |
| Minimum Input Frequency | 50 Hz |
| Minimum Input Voltage | 100 V |
| Depth (mm) | 180 mm |
| Height (mm) | 44 mm |
| Width (mm) | 294 mm |
| External Color | Black |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 90 % |
| Minimum Operating Ambient Temperature | 0 °C |
| Minimum Operating Humidity | 10 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 60 month(s) |
| Warranty validation Criteria | Serial Number |
| Pack Weight Brutto (kg) | 1 kg |
| Pieces in pack | 1 |
| Box Weight Brutto (kg) | 22 kg |
| Packs in Box | 20 |
| Package Type | Retail |
| EAN Code | 6935364021245 |
