| Number of Ports | 16 x 10Base-T/100Base-TX/1000Base-TX (Ethernet/Fast Ethernet/Gigabit Ethernet) |
| Total Number of Ports | 16 |
| Switching Protocol | Ethernet |
| Switching Method | Store and Forward |
| MAC Address Table Size | 8K |
| Data Transmission | Full Duplex |
| Networking Compliant Standards | IEEE 802.3 <br/>IEEE 802.3ab <br/>IEEE 802.3af <br/>IEEE 802.3u <br/>IEEE 802.3x <br/>IEEE 802.3at |
| Networking Features | Auto-Negotiation <br/>Jumbo Frames Support <br/>MDI/MDI-X switch <br/>Power over Ethernet (PoE) <br/>8 Ports PoE <br/>Power over Ethernet plus (PoE+) |
| Device Location | External |
| Mounting Capability | Desktop/Rackmount |
| Standard Rack Height | 1U |
| Certifications | FCC, CE, RoHS |
| Power Consumption Operational | 140.1 W |
| Depth (mm) | 180 mm |
| Height (mm) | 44 mm |
| Width (mm) | 294 mm |
| External Color | Black |
| Maximum Operating Ambient Temperature | 40 °C |
| Maximum Operating Humidity | 90 % |
| Minimum Operating Ambient Temperature | 0 °C |
| Minimum Operating Humidity | 10 % |
| Warranty Products Returnable | Yes |
| Warranty Term (month) | 60 month(s) |
| Warranty validation Criteria | Serial Number |
| Pack Weight Brutto (kg) | 2.45 kg |
| Pack Weight Netto (kg) | 2.45 kg |
| Pieces in pack | 1 |
| Box Weight Brutto (kg) | 19.6 kg |
| Retail Packaging Net Weight Carton | 2.45 kg |
| Retail Packaging Net Weight Plastic | 2.45 kg |
| Packs in Box | 8 |
| Package Type | Box |
| Economic operator in EU / authorized representative | TP-LINK Deutschland GmbH |
| Postal address | Am Trippelsberg 100, 40589 Dusseldorf, Germany |
| Electronic address | https://www.tp-link.com/de/ |
